Overview
The GDPV-32HZ Direct Current Fuse Base 1P/2P is designed for safe and efficient circuit protection in photovoltaic (PV) and DC power systems. Built to handle up to 32A at 1000V DC, this fuse base ensures stable performance under continuous load conditions. It supports 10x38mm fuse links, making it ideal for use in solar array junction boxes, inverters, and battery storage units.
With durable materials and a compact DIN-rail mountable design, the GDPV-32HZ is a reliable DC fuse holder for demanding renewable energy applications.
Product Features
- High Voltage & Current Rating: Supports up to 1000V DC / 32A, ideal for photovoltaic and industrial systems.
- Flexible Configuration: Available in 1-pole and 2-pole (1P/2P) options for diverse connection needs.
- Compact & Durable Build: Flame-retardant housing provides excellent thermal and electrical insulation.
- Universal Compatibility: Designed for 10x38mm PV fuse links, suitable for most solar fuse applications.
- Safe & Reliable Connection: Ensures firm contact for consistent current flow and minimal power loss.
- Easy Installation: DIN-rail mounting for quick assembly in PV combiner boxes or control panels.
Keywords used: 32A DC fuse base, PV DC fuse base 32A, 10x38mm fuse base, GDPV-32HZ 1000V DC fuse holder.
Technical Specifications
| Item | Specification |
|---|---|
| Model | GDPV-32HZ |
| Rated Current | 32A |
| Rated Voltage | 1000V DC |
| Fuse Size | 10x38mm |
| Poles | 1P / 2P |
| Mounting | 35mm DIN Rail |
| Operating Temperature | -25°C ~ +55°C |
| Housing Material | Flame-Retardant Thermoplastic |
| Protection Grade | IP20 |
| Application | Solar PV System, DC Circuit Protection |
| Standards | IEC / EN 60269-6 compliant |
Applications
The GDPV-32HZ fuse base is widely used in photovoltaic power generation, energy storage, and DC distribution systems, providing secure and efficient protection.
Typical applications include:
- PV combiner boxes and inverter input circuits
- Solar panel string protection
- Energy storage and DC control systems
- Industrial DC power distribution cabinets
- Battery management and charging stations
Long-tail keyword integration: solar fuse base 32A, 1000V DC fuse holder, fuse base for PV string system.
Why Choose Us
As a professional DC fuse base manufacturer and supplier, we provide durable, safe, and customizable products for solar and industrial applications.
Our advantages include:
- Strict quality control and full compliance with IEC standards
- OEM/ODM support for branded or customized designs
- Fast global shipping and reliable after-sales service
- Over 10 years of experience in PV fuse protection solutions
Choose us as your trusted DC protection component provider for consistent quality and performance.
FAQ
What is the minimum order quantity (MOQ)?
Our standard MOQ is 100 pieces per model. Bulk orders are eligible for discount pricing.
Can I customize the logo or fuse holder color?
Yes, we provide OEM/ODM services including logo printing, color customization, and packaging options.
What is the delivery time?
Usually within 7–15 working days depending on order quantity and customization requirements.
Do you offer samples for testing?
Yes, samples are available for functional testing before bulk purchase.
Are your products certified?
All GDPV-32HZ fuse bases comply with IEC/EN 60269 standards and undergo full quality inspection before shipment.
